Suspension Spring Coiling Machine

1. Suspension spring coiling machine uses Taiwan imported computer control system and servo motors.
2. This spring forming machine consists of machine tool spindle box, pitch part, molding part, electrical part and hydraulic part
3. Spindle box and pitch parts are driven by spindle rotation and pitch longitudinal movement according to the deceleration of servo motor. Electrical part adopts two axis numerical controlling system.
4. The wire used for this spring coiling machine should be in heating condition. Use a core and spring coil with the wire diameter of 10-60mm. It is suitable for the rolling cylinder, cone, convex, tension spring and compression spring, especially high precision automobile suspension spring.


Main Technical Data

Item LB-CN400
1 Wire size Φ12-Φ40mm
2 Axis 4
3 Outside diameter Max. Φ300mm
4 Pitch 0-150mm
5 Total power 27.4kw
6 Power AC380V/50HZ
7 Weight 2100KG
